Product details
Identification
| Category | Hoods / Housings |
|---|
| Series of hoods/housings | Han A® |
|---|
| Type of hood/housing | Cable to cable housing |
|---|
Version
| Size | 3 A |
|---|
| Version | Top entry |
|---|
| Number of cable entries | 1 |
|---|
| Cable entry | 1x M20 |
|---|
| Locking type | Single locking lever |
|---|
| Field of application | Standard Hoods/housings for industrial applications |
|---|
| Pack contents | Please order seal screw separately. |
|---|
Technical characteristics
| Limiting temperature | -40 ... +125 °C |
|---|
| Note on the limiting temperature | For use as a connector according to IEC 61984. |
|---|
| Degree of protection acc. to IEC 60529 | IP44 |
|---|
| IP65 With seal screw |
| IP67 With seal screw |
| Type rating acc. to UL 50 / UL 50E | 12 |
|---|
Material properties
| Material (hood/housing) | Zinc die-cast |
|---|
| Surface (hood/housing) | Powder-coated |
|---|
| Colour (hood/housing) | RAL 7037 (dust grey) |
|---|
| Material (locking) | Steel |
|---|
| Surface (locking) | Zinc plated |
|---|
| RoHS | compliant |
|---|
| ELV status | compliant |
|---|
| China RoHS | e |
|---|
| REACH Annex XVII substances | Not contained |
|---|
| REACH ANNEX XIV substances | Not contained |
|---|
| REACH SVHC substances | Not contained |
|---|
| California Proposition 65 substances | Not contained |
|---|
| Fire protection on railway vehicles | EN 45545-2 (2020-08) |
|---|
| Requirement set with Hazard Levels | R1 (HL 1-3) |
|---|
| R7 (HL 1-3) |
