Maximum angle of view 91.6° (Max Lens shift diagonal)
Projected angle WQXGA H:61.3 V:38.4 D:72.3 WUXGA H:65.7 V:41.1 D:77.5 Full HD H:66.0 V:37.1 D:75.7 SXGA+ H:60.7 V:45.5 D:75.9 WXGA H:59.5 V:33.4 D:68.2
Lens Shift WQXGA H:±17% V:±37% WUXGA H:±12% V:±27% Full HD H:±13% V:±35% SXGA+ H:±15% V:±25% WXGA H:±21% V:±54%
Focus adjustment function*1 yes
Optical masking*2 yes
Focal length(f) 9.0 mm
F Value 2.5
Auto Lens Identi cation function Compatible models : PT-RQ32K/RZ31K/RS30K/RQ22K/RZ21K/RS20K
